Crydom MCXE380D5
- Mfg. Part Number
- MCXE380D5
- Manufacturer
- Crydom
- Product Category
- Solid State Relays
- Brief Description
- RELAY SSR DC 380V 5A AC OUT SIP
- Datasheet Download
- MCXE380D5.pdf
Availability of MCXE380D5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 19.88000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MCXE380D5, we specialize in Crydom all series electronic components. MCXE380D5 can be shipped within 24 hours after order. If you have any demands for MCXE380D5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MCXE380D5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MCXE380D5
| Internal Part Number | EIS-MCXE380D5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Other Related Documents | Declaration of Conformity | |
| 3D Model | MCX Series.satMCX Series.dwgMCX Series.stp | |
| Standard Package | 25 | |
| Category | Relays | |
| Family | Solid State Relays | |
| Series | MCX | |
| Packaging | Bulk | |
| Circuit | SPST-NO (1 Form A) | |
| Output Type | AC, Zero Cross | |
| On-State Resistance | - | |
| Load Current | 5A | |
| Voltage - Input | 15 ~ 32VDC | |
| Voltage - Load | 48 ~ 530 V | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Package / Case | 4-SIP | |
| Supplier Device Package | 4-SIP | |
| Relay Type | Relay | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MCXE380D5 | |
| Related Links | MCXE, MCXE380D5 Datasheet, Crydom Distributor | |
