TDK Corporation MHQ1005P2N8BTD25
-MHQ-Series.jpg)
- Mfg. Part Number
- MHQ1005P2N8BTD25
- Manufacturer
- TDK Corporation
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 2.8NH 900MA 80 MOHM
- Datasheet Download
- MHQ1005P2N8BTD25.pdf
Availability of MHQ1005P2N8BTD25
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.11625
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MHQ1005P2N8BTD25, we specialize in TDK Corporation all series electronic components. MHQ1005P2N8BTD25 can be shipped within 24 hours after order. If you have any demands for MHQ1005P2N8BTD25, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MHQ1005P2N8BTD25 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MHQ1005P2N8BTD25
| Internal Part Number | EIS-MHQ1005P2N8BTD25 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | High Frequency Inductor Family | |
| Standard Package | 10,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | Automotive, AEC-Q200, MHQ-P | |
| Packaging | Tape & Reel (TR) | |
| Type | Multilayer | |
| Material - Core | Non-Magnetic | |
| Inductance | 2.8nH | |
| Tolerance | ±0.1nH | |
| Current Rating | 900mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 80 mOhm Max | |
| Q @ Freq | 23 @ 250MHz | |
| Frequency - Self Resonant | 6.5GHz | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 100MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 0402 (1006 Metric) | |
| Size / Dimension | 0.039" L x 0.024" W (1.00mm x 0.60mm) | |
| Height - Seated (Max) | 0.024" (0.60mm) | |
| Supplier Device Package | 1006 (0402) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MHQ1005P2N8BTD25 | |
| Related Links | MHQ1005P, MHQ1005P2N8BTD25 Datasheet, TDK Corporation Distributor | |
