TE Connectivity Raychem Circuit Protection MINISMDC014F-2
- Mfg. Part Number
- MINISMDC014F-2
- Manufacturer
- TE Connectivity Raychem Circuit Protection
- Product Category
- PTC Resettable Fuses
- Brief Description
- POLYSWITCH .14A RESET FUSE SMD
- Datasheet Download
- MINISMDC014F-2.pdf
Availability of MINISMDC014F-2
Available Quantity
61484 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.17200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MINISMDC014F-2, we specialize in TE Connectivity Raychem Circuit Protection all series electronic components. MINISMDC014F-2 can be shipped within 24 hours after order. If you have any demands for MINISMDC014F-2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MINISMDC014F-2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MINISMDC014F-2
| Internal Part Number | EIS-MINISMDC014F-2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2A (4 Weeks) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Circuit Protection Products | |
| Video File | TE Connectivity PolySwitch Devices -- Another Geek Moment | |
| Featured Product | SMD Series Circuit Protection | |
| Standard Package | 1 | |
| Category | Circuit Protection | |
| Family | PTC Resettable Fuses | |
| Series | PolySwitch® | |
| Packaging | Cut Tape (CT) | |
| Voltage - Max | 60V | |
| Current - Max | 10A | |
| Current - Hold (Ih) (Max) | 140mA | |
| Current - Trip (It) | 280mA | |
| R Min/Max | 1.500 ~ 6.000 Ohm | |
| Time to Trip | 0.008s | |
| Package / Case | 1812 (4532 Metric), Concave | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MINISMDC014F-2 | |
| Related Links | MINISMD, MINISMDC014F-2 Datasheet, TE Connectivity Raychem Circuit Protection Distributor | |
MINISMDC014F-2 Details Description
