TDK Corporation MLZ2012M1R5HTD25
- Mfg. Part Number
- MLZ2012M1R5HTD25
- Manufacturer
- TDK Corporation
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 1.5UH 700MA 182 MOHM
- Datasheet Download
- MLZ2012M1R5HTD25.pdf
Availability of MLZ2012M1R5HTD25
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.07518
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MLZ2012M1R5HTD25, we specialize in TDK Corporation all series electronic components. MLZ2012M1R5HTD25 can be shipped within 24 hours after order. If you have any demands for MLZ2012M1R5HTD25, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MLZ2012M1R5HTD25 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MLZ2012M1R5HTD25
| Internal Part Number | EIS-MLZ2012M1R5HTD25 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | Automotive, AEC-Q200, MLZ | |
| Packaging | Tape & Reel (TR) | |
| Type | Multilayer | |
| Material - Core | Ferrite | |
| Inductance | 1.5µH | |
| Tolerance | ±20% | |
| Current Rating | 700mA | |
| Current - Saturation | 550mA | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 182 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 2MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 0805 (2012 Metric) | |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | |
| Height - Seated (Max) | 0.049" (1.25mm) | |
| Supplier Device Package | 0805 (2012 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MLZ2012M1R5HTD25 | |
| Related Links | MLZ2012M, MLZ2012M1R5HTD25 Datasheet, TDK Corporation Distributor | |
MLZ2012M1R5HTD25 Details Description
