Panasonic Electronic Components MN13812SGU
,TO-226_straightlead.jpg)
- Mfg. Part Number
- MN13812SGU
- Manufacturer
- Panasonic Electronic Components
- Product Category
- PMIC - Supervisors
- Brief Description
- VOLT DETECT IC CMOS IV 2.4V TO-9
- Datasheet Download
- MN13812SGU.pdf
Availability of MN13812SGU
Available Quantity
8020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.35754
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MN13812SGU, we specialize in Panasonic Electronic Components all series electronic components. MN13812SGU can be shipped within 24 hours after order. If you have any demands for MN13812SGU, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MN13812SGU Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MN13812SGU
| Internal Part Number | EIS-MN13812SGU | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Supervisors | |
| Series | - | |
| Packaging | Tape & Box (TB) | |
| Type | Simple Reset/Power-On Reset | |
| Number of Voltages Monitored | 1 | |
| Output | CMOS Inverted | |
| Reset | Active Low | |
| Reset Timeout | 3 µs Typical | |
| Voltage - Threshold | 2.4V | |
| Operating Temperature | -20°C ~ 70°C | |
| Mounting Type | Through Hole | |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) Formed Leads | |
| Supplier Device Package | TO-92 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MN13812SGU | |
| Related Links | MN138, MN13812SGU Datasheet, Panasonic Electronic Components Distributor | |
MN13812SGU Details Description
