NXP Semiconductors/Freescale Semiconductor, Inc. MPX5010D
- Mfg. Part Number
- MPX5010D
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- Pressure Sensors, Transducers
- Brief Description
- SENSOR DIFF PRESS 1.45PSI MAX
- Datasheet Download
- MPX5010D.pdf
Availability of MPX5010D
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MPX5010D, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. MPX5010D can be shipped within 24 hours after order. If you have any demands for MPX5010D, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MPX5010D Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MPX5010D
| Internal Part Number | EIS-MPX5010D | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Sensors, Transducers | |
| Family | Pressure Sensors, Transducers | |
| Series | MPX5010 | |
| Pressure Type | Differential | |
| Operating Pressure | 1.45 PSI (10 kPa) | |
| Output Type | Analog, Voltage | |
| Output | 0.2 V ~ 4.7 V | |
| Accuracy | ±5% | |
| Voltage - Supply | 4.75 V ~ 5.25 V | |
| Port Size | - | |
| Port Style | No Port | |
| Features | Temperature Compensated | |
| Termination Style | PCB | |
| Maximum Pressure | 5.8 PSI (40 kPa) | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 6-SIP Module | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MPX5010D | |
| Related Links | MPX5, MPX5010D Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
