E-Switch MS0850500F080C1A
- Mfg. Part Number
- MS0850500F080C1A
- Manufacturer
- E-Switch
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SW MINI SNAP ACTION SPDT 5A
- Datasheet Download
- MS0850500F080C1A.pdf
Availability of MS0850500F080C1A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.66720
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MS0850500F080C1A, we specialize in E-Switch all series electronic components. MS0850500F080C1A can be shipped within 24 hours after order. If you have any demands for MS0850500F080C1A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MS0850500F080C1A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MS0850500F080C1A
| Internal Part Number | EIS-MS0850500F080C1A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Switch Basics Power Switch Overview | |
| RoHS Information | MS Series RoHS Cert of Compliance | |
| 3D Model | MS0850500FyyyC1A.stpMS085yy00FyyyC1A.stp | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | MS | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 5A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Round (Pin Plunger) | |
| Mounting Type | Chassis Mount | |
| Termination Style | Quick Connect - 0.110" (2.8mm) | |
| Ingress Protection | - | |
| Features | - | |
| Operating Force, Torque | 80gf | |
| Release Force | 25gf | |
| Pretravel | 0.043" (1.1mm) | |
| Differential Travel | - | |
| Overtravel | - | |
| Operating Position | 0.335" (8.5mm) | |
| Mechanical Life | 1,000,000 Cycles | |
| Electrical Life | 50,000 Cycles | |
| Operating Temperature | -25°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MS0850500F080C1A | |
| Related Links | MS085050, MS0850500F080C1A Datasheet, E-Switch Distributor | |
MS0850500F080C1A Details Description
