Amphenol Aerospace Operations MS17346R20N33S
- Mfg. Part Number
- MS17346R20N33S
- Manufacturer
- Amphenol Aerospace Operations
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 11POS BOX MT W/SCKT
- Datasheet Download
- MS17346R20N33S.pdf
Availability of MS17346R20N33S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 312.76280
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MS17346R20N33S, we specialize in Amphenol Aerospace Operations all series electronic components. MS17346R20N33S can be shipped within 24 hours after order. If you have any demands for MS17346R20N33S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MS17346R20N33S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MS17346R20N33S
| Internal Part Number | EIS-MS17346R20N33S | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | Military, MIL-DTL-22992 | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 11 | |
| Shell Size - Insert | 20-33 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Flange | |
| Termination | Solder Cup | |
| Fastening Type | Threaded | |
| Orientation | N (Normal) | |
| Ingress Protection | Waterproof | |
| Shell Material, Finish | Aluminum, Anodic Coating (Alumilite) | |
| Contact Finish | Silver | |
| Features | - | |
| Contact Finish Thickness | - | |
| Current Rating | - | |
| Voltage - Rated | 500VAC, 700VDC | |
| Operating Temperature | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MS17346R20N33S | |
| Related Links | MS17346, MS17346R20N33S Datasheet, Amphenol Aerospace Operations Distributor | |
