Keystone Electronics MS27249-3E5
- Mfg. Part Number
- MS27249-3E5
- Manufacturer
- Keystone Electronics
- Product Category
- Terminal Strips and Turret Boards
- Brief Description
- TERM TURRET SNGL GEE 13.125" L
- Datasheet Download
- MS27249-3E5.pdf
Availability of MS27249-3E5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 68.04000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MS27249-3E5, we specialize in Keystone Electronics all series electronic components. MS27249-3E5 can be shipped within 24 hours after order. If you have any demands for MS27249-3E5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MS27249-3E5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MS27249-3E5
| Internal Part Number | EIS-MS27249-3E5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Strips and Turret Boards | |
| Series | - | |
| Type | Turret Board, Scored | |
| Terminal Type | Turret, Single End, Double Turret | |
| Number of Positions | 50 | |
| Pitch | 0.375" (9.53mm) | |
| Number of Rows | 2 | |
| Row Spacing | 1.500" (38.10mm) | |
| Board Size | 13.125" L x 2.000" W x 0.125" H (333.38mm x 50.80mm x 3.18mm) | |
| Material - Board | Glass Epoxy | |
| Features | - | |
| Material Flammability Rating | - | |
| Contact Finish | Tin | |
| Contact Material | Brass | |
| Mounting Hole Diameter | 0.120" (3.05mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MS27249-3E5 | |
| Related Links | MS272, MS27249-3E5 Datasheet, Keystone Electronics Distributor | |
MS27249-3E5 Details Description
