Amphenol Aerospace Operations MS27474E8F98SA
- Mfg. Part Number
- MS27474E8F98SA
- Manufacturer
- Amphenol Aerospace Operations
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 3POS JAM NUT W/SCKT
- Datasheet Download
- MS27474E8F98SA.pdf
Availability of MS27474E8F98SA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 75.42360
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MS27474E8F98SA, we specialize in Amphenol Aerospace Operations all series electronic components. MS27474E8F98SA can be shipped within 24 hours after order. If you have any demands for MS27474E8F98SA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MS27474E8F98SA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MS27474E8F98SA
| Internal Part Number | EIS-MS27474E8F98SA | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | MIL-DTL-38999 Series I, II | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | Military, MIL-DTL-38999 Series II | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 3 | |
| Shell Size - Insert | 8-98 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Bulkhead - Front Side Nut | |
| Termination | Crimp | |
| Fastening Type | Bayonet Lock | |
| Orientation | A | |
| Ingress Protection | Environment Resistant | |
| Shell Material, Finish | Aluminum, Nickel Plated, Electroless | |
| Contact Finish | Gold | |
| Features | - | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Current Rating | 7.5A | |
| Voltage - Rated | 600VAC, 850VDC | |
| Operating Temperature | -65°C ~ 200°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MS27474E8F98SA | |
| Related Links | MS27474, MS27474E8F98SA Datasheet, Amphenol Aerospace Operations Distributor | |
MS27474E8F98SA Details Description
