Amphenol Industrial MS3102E22-4S
- Mfg. Part Number
- MS3102E22-4S
- Manufacturer
- Amphenol Industrial
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 4POS BOX MNT W/SCKT
- Datasheet Download
- MS3102E22-4S.pdf
Availability of MS3102E22-4S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 19.11720
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MS3102E22-4S, we specialize in Amphenol Industrial all series electronic components. MS3102E22-4S can be shipped within 24 hours after order. If you have any demands for MS3102E22-4S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MS3102E22-4S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MS3102E22-4S
| Internal Part Number | EIS-MS3102E22-4S | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | 26482 Series 1 Miniature Cylindrical Connector Mil-DTL-5015 and AC Threaded Connectors | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-5015 Type | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 4 | |
| Shell Size - Insert | 22-4 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Flange | |
| Termination | Solder Cup | |
| Fastening Type | Threaded | |
| Orientation | N (Normal) | |
| Ingress Protection | Environment Resistant | |
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated | |
| Contact Finish | Silver | |
| Features | - | |
| Contact Finish Thickness | - | |
| Current Rating | - | |
| Voltage - Rated | 500VAC, 700VDC | |
| Operating Temperature | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MS3102E22-4S | |
| Related Links | MS3102, MS3102E22-4S Datasheet, Amphenol Industrial Distributor | |
