Souriau Connection Technology MS3476W2255PY
- Mfg. Part Number
- MS3476W2255PY
- Manufacturer
- Souriau Connection Technology
- Product Category
- Circular Connectors
- Brief Description
- CONN PLUG 55POS STRAIGHT W/PINS
- Datasheet Download
- MS3476W2255PY.pdf
Availability of MS3476W2255PY
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 42.81600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MS3476W2255PY, we specialize in Souriau Connection Technology all series electronic components. MS3476W2255PY can be shipped within 24 hours after order. If you have any demands for MS3476W2255PY, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MS3476W2255PY Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MS3476W2255PY
| Internal Part Number | EIS-MS3476W2255PY | |
| Lead Free Status / RoHS Status | Lead free / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | Military, MIL-DTL-26482 G Series II | |
| Packaging | Bulk | |
| Connector Type | Plug, Male Pins | |
| Number of Positions | 55 | |
| Shell Size - Insert | 22-55 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Fastening Type | Bayonet Lock | |
| Orientation | Y | |
| Ingress Protection | - | |
| Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated | |
| Contact Finish | Gold | |
| Features | - | |
| Contact Finish Thickness | - | |
| Current Rating | 7.5A | |
| Voltage - Rated | - | |
| Operating Temperature | -55°C ~ 175°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MS3476W2255PY | |
| Related Links | MS3476, MS3476W2255PY Datasheet, Souriau Connection Technology Distributor | |
MS3476W2255PY Details Description
