ITT Cannon, LLC MS3476W24-19AX
- Mfg. Part Number
- MS3476W24-19AX
- Manufacturer
- ITT Cannon, LLC
- Product Category
- Circular Connectors - Housings
- Brief Description
- CONN HSNG PLUG 19POS STRAIGHT
- Datasheet Download
- MS3476W24-19AX.pdf
Availability of MS3476W24-19AX
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 256.40680
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MS3476W24-19AX, we specialize in ITT Cannon, LLC all series electronic components. MS3476W24-19AX can be shipped within 24 hours after order. If you have any demands for MS3476W24-19AX, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MS3476W24-19AX Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MS3476W24-19AX
| Internal Part Number | EIS-MS3476W24-19AX | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors - Housings | |
| Series | Military, MIL-DTL-26482 Series II, PV | |
| Packaging | Bulk | |
| Connector Type | Plug for Male Contacts | |
| Number of Positions | 19 | |
| Shell Size - Insert | 24-19 | |
| Shell Size, MIL | - | |
| Contact Type | Crimp | |
| Contact Size | 12 | |
| Mounting Type | Free Hanging (In-Line) | |
| Fastening Type | Bayonet Lock | |
| Orientation | X | |
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated | |
| Ingress Protection | - | |
| Features | - | |
| Note | Contacts Not Provided | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MS3476W24-19AX | |
| Related Links | MS3476W, MS3476W24-19AX Datasheet, ITT Cannon, LLC Distributor | |
