Fairchild Semiconductor NC7WZ132L8X
- Mfg. Part Number
- NC7WZ132L8X
- Manufacturer
- Fairchild Semiconductor
- Product Category
- Logic - Gates and Inverters
- Brief Description
- IC GATE NAND 2CH 2-INP 8MICROPAK
- Datasheet Download
- NC7WZ132L8X.pdf
Availability of NC7WZ132L8X
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.13236
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of NC7WZ132L8X, we specialize in Fairchild Semiconductor all series electronic components. NC7WZ132L8X can be shipped within 24 hours after order. If you have any demands for NC7WZ132L8X, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- NC7WZ132L8X Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
NC7WZ132L8X
| Internal Part Number | EIS-NC7WZ132L8X | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Die Material, Mold Compound 03/Oct/2008 Marking Content 19/Nov/2013 | |
| Standard Package | 5,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Gates and Inverters | |
| Series | 7WZ | |
| Packaging | Tape & Reel (TR) | |
| Logic Type | NAND Gate | |
| Number of Circuits | 2 | |
| Number of Inputs | 2 | |
| Features | Schmitt Trigger | |
| Voltage - Supply | 1.65 V ~ 5.5 V | |
| Current - Quiescent (Max) | 1µA | |
| Current - Output High, Low | 32mA, 32mA | |
| Logic Level - Low | 0.2 V ~ 1.2 V | |
| Logic Level - High | 1.4 V ~ 3.6 V | |
| Max Propagation Delay @ V, Max CL | 4.5ns @ 5V, 50pF | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Supplier Device Package | 8-MicroPak™ | |
| Package / Case | 8-XFQFN | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | NC7WZ132L8X | |
| Related Links | NC7WZ, NC7WZ132L8X Datasheet, Fairchild Semiconductor Distributor | |
NC7WZ132L8X Details Description
