ON Semiconductor NTMFS4985NFT3G
- Mfg. Part Number
- NTMFS4985NFT3G
- Manufacturer
- ON Semiconductor
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 30V 65A SO8FL
- Datasheet Download
- NTMFS4985NFT3G.pdf
Availability of NTMFS4985NFT3G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.53200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of NTMFS4985NFT3G, we specialize in ON Semiconductor all series electronic components. NTMFS4985NFT3G can be shipped within 24 hours after order. If you have any demands for NTMFS4985NFT3G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- NTMFS4985NFT3G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
NTMFS4985NFT3G
| Internal Part Number | EIS-NTMFS4985NFT3G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | Wafer Capacity Expansion 21/May/2015 | |
| Standard Package | 5,000 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 30V | |
| Current - Continuous Drain (Id) @ 25°C | 17.5A (Ta), 65A (Tc) | |
| Rds On (Max) @ Id, Vgs | 3.4 mOhm @ 30A, 10V | |
| Vgs(th) (Max) @ Id | 2.3V @ 1mA | |
| Gate Charge (Qg) @ Vgs | 30.5nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 2100pF @ 15V | |
| Power - Max | 1.63W | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-PowerTDFN, 5 Leads | |
| Supplier Device Package | 5-DFN, 8-SO Flat Lead (5x6) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | NTMFS4985NFT3G | |
| Related Links | NTMFS49, NTMFS4985NFT3G Datasheet, ON Semiconductor Distributor | |
NTMFS4985NFT3G Details Description
