ON Semiconductor NTMFS5844NLT1G
- Mfg. Part Number
- NTMFS5844NLT1G
- Manufacturer
- ON Semiconductor
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 60V 60A SO-8FL
- Datasheet Download
- NTMFS5844NLT1G.pdf
Availability of NTMFS5844NLT1G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.32208
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of NTMFS5844NLT1G, we specialize in ON Semiconductor all series electronic components. NTMFS5844NLT1G can be shipped within 24 hours after order. If you have any demands for NTMFS5844NLT1G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- NTMFS5844NLT1G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
NTMFS5844NLT1G
| Internal Part Number | EIS-NTMFS5844NLT1G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,500 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 60V | |
| Current - Continuous Drain (Id) @ 25°C | 11.2A (Ta) | |
| Rds On (Max) @ Id, Vgs | 12 mOhm @ 10A, 10V | |
| Vgs(th) (Max) @ Id | 2.3V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 30nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 1460pF @ 25V | |
| Power - Max | 3W | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-PowerTDFN, 5 Leads | |
| Supplier Device Package | 5-DFN, 8-SO Flat Lead (5x6) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | NTMFS5844NLT1G | |
| Related Links | NTMFS58, NTMFS5844NLT1G Datasheet, ON Semiconductor Distributor | |
NTMFS5844NLT1G Details Description
