API Delevan P160R-124JS
- Mfg. Part Number
- P160R-124JS
- Manufacturer
- API Delevan
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 120UH 157MA 5 OHM SMD
- Datasheet Download
- P160R-124JS.pdf
Availability of P160R-124JS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.05700
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of P160R-124JS, we specialize in API Delevan all series electronic components. P160R-124JS can be shipped within 24 hours after order. If you have any demands for P160R-124JS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- P160R-124JS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
P160R-124JS
| Internal Part Number | EIS-P160R-124JS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | P160R | |
| Packaging | Bulk | |
| Type | - | |
| Material - Core | Ferrite | |
| Inductance | 120µH | |
| Tolerance | ±5% | |
| Current Rating | 157mA | |
| Current - Saturation | 139mA | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 5 Ohm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.155" L x 0.125" W (3.68mm x 3.18mm) | |
| Height - Seated (Max) | 0.100" (2.54mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | P160R-124JS | |
| Related Links | P160R, P160R-124JS Datasheet, API Delevan Distributor | |
P160R-124JS Details Description
