API Delevan P1812R-122H
- Mfg. Part Number
- P1812R-122H
- Manufacturer
- API Delevan
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 1.2UH 1A 199 MOHM SMD
- Datasheet Download
- P1812R-122H.pdf
Availability of P1812R-122H
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.04800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of P1812R-122H, we specialize in API Delevan all series electronic components. P1812R-122H can be shipped within 24 hours after order. If you have any demands for P1812R-122H, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- P1812R-122H Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
P1812R-122H
| Internal Part Number | EIS-P1812R-122H | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 650 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | P1812R | |
| Packaging | Tape & Reel (TR) | |
| Type | - | |
| Material - Core | Ferrite | |
| Inductance | 1.2µH | |
| Tolerance | ±3% | |
| Current Rating | 1A | |
| Current - Saturation | 2.158A | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 199 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 1kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.190" L x 0.134" W (4.83mm x 3.40mm) | |
| Height - Seated (Max) | 0.134" (3.40mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | P1812R-122H | |
| Related Links | P1812, P1812R-122H Datasheet, API Delevan Distributor | |
P1812R-122H Details Description
