Sullins Connector Solutions PBC19DFDN
- Mfg. Part Number
- PBC19DFDN
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Rectangular Connectors - Headers, Male Pins
- Brief Description
- CONN HEADER .100 DUAL STR 38POS
- Datasheet Download
- PBC19DFDN.pdf
Availability of PBC19DFDN
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.09800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PBC19DFDN, we specialize in Sullins Connector Solutions all series electronic components. PBC19DFDN can be shipped within 24 hours after order. If you have any demands for PBC19DFDN, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PBC19DFDN Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PBC19DFDN
| Internal Part Number | EIS-PBC19DFDN | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Male Pins | |
| Series | - | |
| Packaging | Bulk | |
| Contact Type | Male Pin | |
| Connector Type | Header, Unshrouded, Breakaway | |
| Number of Positions | 38 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 2 | |
| Row Spacing | 0.100" (2.54mm) | |
| Contact Mating Length | 0.318" (8.08mm) | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 10µin (0.25µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PBC19DFDN | |
| Related Links | PBC1, PBC19DFDN Datasheet, Sullins Connector Solutions Distributor | |
PBC19DFDN Details Description
