Sharp Microelectronics PC4H510NIP
- Mfg. Part Number
- PC4H510NIP
- Manufacturer
- Sharp Microelectronics
- Product Category
- Optoisolators - Transistor, Photovoltaic Output
- Brief Description
- OPTOISOLATOR 2.5KV TRANS 4SMD
- Datasheet Download
- PC4H510NIP.pdf
Availability of PC4H510NIP
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PC4H510NIP, we specialize in Sharp Microelectronics all series electronic components. PC4H510NIP can be shipped within 24 hours after order. If you have any demands for PC4H510NIP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PC4H510NIP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PC4H510NIP
| Internal Part Number | EIS-PC4H510NIP | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Isolators | |
| Family | Optoisolators - Transistor, Photovoltaic Output | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Channels | 1 | |
| Voltage - Isolation | 2500Vrms | |
| Current Transfer Ratio (Min) | 40% @ 5mA | |
| Current Transfer Ratio (Max) | 240% @ 5mA | |
| Turn On / Turn Off Time (Typ) | - | |
| Rise / Fall Time (Typ) | 4µs, 5µs | |
| Input Type | DC | |
| Output Type | Transistor | |
| Voltage - Output (Max) | 350V | |
| Current - Output / Channel | 50mA | |
| Voltage - Forward (Vf) (Typ) | 1.2V | |
| Current - DC Forward (If) (Max) | 50mA | |
| Vce Saturation (Max) | 300mV | |
| Operating Temperature | -25°C ~ 100°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 4-SOIC (0.209", 5.30mm Width) | |
| Supplier Device Package | 4-SOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PC4H510NIP | |
| Related Links | PC4H5, PC4H510NIP Datasheet, Sharp Microelectronics Distributor | |
