LEMO PCA.1S.304.CLLC52Z
- Mfg. Part Number
- PCA.1S.304.CLLC52Z
- Manufacturer
- LEMO
- Product Category
- Circular Connectors
- Brief Description
- CONN INLINE RCPT 4SKT SLD CUP
- Datasheet Download
- PCA.1S.304.CLLC52Z.pdf
Availability of PCA.1S.304.CLLC52Z
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 39.55000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PCA.1S.304.CLLC52Z, we specialize in LEMO all series electronic components. PCA.1S.304.CLLC52Z can be shipped within 24 hours after order. If you have any demands for PCA.1S.304.CLLC52Z, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PCA.1S.304.CLLC52Z Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PCA.1S.304.CLLC52Z
| Internal Part Number | EIS-PCA.1S.304.CLLC52Z | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | 1S | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets and Male Pins | |
| Number of Positions | 4 | |
| Shell Size - Insert | 304 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Solder Cup | |
| Fastening Type | Push-Pull, Detent Lock | |
| Orientation | Keyed | |
| Ingress Protection | IP50 - Dust Protected | |
| Shell Material, Finish | Brass, Chrome Plated | |
| Contact Finish | Gold | |
| Features | Backshell, Shielded | |
| Contact Finish Thickness | - | |
| Current Rating | 10A | |
| Voltage - Rated | - | |
| Operating Temperature | -55°C ~ 250°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PCA.1S.304.CLLC52Z | |
| Related Links | PCA.1S.30, PCA.1S.304.CLLC52Z Datasheet, LEMO Distributor | |
