Hirose Electric Co Ltd PCN10MC-96P-2.54DS
- Mfg. Part Number
- PCN10MC-96P-2.54DS
- Manufacturer
- Hirose Electric Co Ltd
- Product Category
- Backplane Connectors - DIN 41612
- Brief Description
- DIN CONN HEADER 96POS 3ROW R/A
- Datasheet Download
- PCN10MC-96P-2.54DS.pdf
Availability of PCN10MC-96P-2.54DS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PCN10MC-96P-2.54DS, we specialize in Hirose Electric Co Ltd all series electronic components. PCN10MC-96P-2.54DS can be shipped within 24 hours after order. If you have any demands for PCN10MC-96P-2.54DS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PCN10MC-96P-2.54DS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PCN10MC-96P-2.54DS
| Internal Part Number | EIS-PCN10MC-96P-2.54DS | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Connectors, Interconnects | |
| Family | Backplane Connectors - DIN 41612 | |
| Series | PCN10 | |
| Packaging | Tray | |
| Connector Type | Header, Male Pins | |
| Number of Positions | 96 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 3 | |
| Style | C | |
| Level, Class | - | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | - | |
| Operating Temperature | -55°C ~ 85°C | |
| Current Rating | 2A | |
| Material Flammability Rating | UL94 V-0 | |
| Material - Insulation | Polybutylene Terephthalate (PBT) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PCN10MC-96P-2.54DS | |
| Related Links | PCN10MC-9, PCN10MC-96P-2.54DS Datasheet, Hirose Electric Co Ltd Distributor | |
