Bourns Inc. PCW1D-C24-BAB102L
- Mfg. Part Number
- PCW1D-C24-BAB102L
- Manufacturer
- Bourns Inc.
- Product Category
- Rotary Potentiometers, Rheostats
- Brief Description
- POT 1K OHM 3/4W PLASTIC LINEAR
- Datasheet Download
- PCW1D-C24-BAB102L.pdf
Availability of PCW1D-C24-BAB102L
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.96911
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PCW1D-C24-BAB102L, we specialize in Bourns Inc. all series electronic components. PCW1D-C24-BAB102L can be shipped within 24 hours after order. If you have any demands for PCW1D-C24-BAB102L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PCW1D-C24-BAB102L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PCW1D-C24-BAB102L
| Internal Part Number | EIS-PCW1D-C24-BAB102L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | PCW1D Material Declaration | |
| PCN Other | Multiple Changes 01/Dec/2012 | |
| Standard Package | 45 | |
| Category | Potentiometers, Variable Resistors | |
| Family | Rotary Potentiometers, Rheostats | |
| Series | PC-Slimline | |
| Packaging | Tray | |
| Taper | Linear | |
| Resistance (Ohms) | 1k | |
| Tolerance | ±20% | |
| Number of Gangs | 1 | |
| Built in Switch | None | |
| Power (Watts) | 0.75W, 3/4W | |
| Temperature Coefficient | ±1000ppm/°C | |
| Number of Turns | 1 | |
| Rotation | 300° | |
| Adjustment Type | Top Adjustment | |
| Resistive Material | Conductive Plastic | |
| Termination Style | PCB Pins | |
| Actuator Type | Flatted | |
| Actuator Length | 0.750" (19.05mm) | |
| Actuator Diameter | 0.250" (6.35mm) | |
| Bushing Thread | M9 x 0.75 | |
| Mounting Type | Panel Mount | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PCW1D-C24-BAB102L | |
| Related Links | PCW1D-C2, PCW1D-C24-BAB102L Datasheet, Bourns Inc. Distributor | |
PCW1D-C24-BAB102L Details Description
