Advanced Photonix, Inc. PDB-C613-2
- Mfg. Part Number
- PDB-C613-2
- Manufacturer
- Advanced Photonix, Inc.
- Product Category
- Optical Sensors - Photodiodes
- Brief Description
- PHOTODIODE RED PVC 86.4MM SQ
- Datasheet Download
- PDB-C613-2.pdf
Availability of PDB-C613-2
Available Quantity
5667 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 22.12800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PDB-C613-2, we specialize in Advanced Photonix, Inc. all series electronic components. PDB-C613-2 can be shipped within 24 hours after order. If you have any demands for PDB-C613-2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PDB-C613-2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PDB-C613-2
| Internal Part Number | EIS-PDB-C613-2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Sensors, Transducers | |
| Family | Optical Sensors - Photodiodes | |
| Series | - | |
| Packaging | Bulk | |
| Wavelength | 950nm | |
| Color - Enhanced | Red | |
| Spectral Range | 350nm ~ 1100nm | |
| Diode Type | - | |
| Responsivity @ nm | - | |
| Response Time | 50ns | |
| Voltage - DC Reverse (Vr) (Max) | 75V | |
| Current - Dark (Typ) | 90nA | |
| Active Area | 86.4mm² | |
| Viewing Angle | - | |
| Operating Temperature | -40°C ~ 100°C | |
| Mounting Type | Free Hanging | |
| Package / Case | Chip with 30 Gage PVC Wire | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PDB-C613-2 | |
| Related Links | PDB-C, PDB-C613-2 Datasheet, Advanced Photonix, Inc. Distributor | |
PDB-C613-2 Details Description
