CUI Inc. PDM2-S5-S5-D
- Mfg. Part Number
- PDM2-S5-S5-D
- Manufacturer
- CUI Inc.
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONVERTER 5V 2W
- Datasheet Download
- PDM2-S5-S5-D.pdf
Availability of PDM2-S5-S5-D
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.49450
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PDM2-S5-S5-D, we specialize in CUI Inc. all series electronic components. PDM2-S5-S5-D can be shipped within 24 hours after order. If you have any demands for PDM2-S5-S5-D, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PDM2-S5-S5-D Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PDM2-S5-S5-D
| Internal Part Number | EIS-PDM2-S5-S5-D | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Thermal Management of Power Supplies | |
| RoHS Information | PDM2-D Series Cert of Compliance | |
| 3D Model | PDM2-S5-S5-D | |
| Standard Package | 25 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | PDM-2 | |
| Packaging | Bulk | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 5.5V | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 400mA | |
| Power (Watts) - Manufacture Series | 2W | |
| Voltage - Isolation | 1.5kV (1500V) | |
| Features | SCP | |
| Mounting Type | Through Hole | |
| Package / Case | 14-DIP Module (6 Leads) | |
| Size / Dimension | 0.79" L x 0.39" W x 0.32" H (20.1mm x 9.9mm x 8.2mm) | |
| Operating Temperature | -40°C ~ 105°C | |
| Efficiency | 85% | |
| Power (Watts) - Max | 2W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PDM2-S5-S5-D | |
| Related Links | PDM2-S, PDM2-S5-S5-D Datasheet, CUI Inc. Distributor | |
PDM2-S5-S5-D Details Description
