Riedon PF2203-0R033J1
- Mfg. Part Number
- PF2203-0R033J1
- Manufacturer
- Riedon
- Product Category
- Through Hole Resistors
- Brief Description
- RES 0.033 OHM 35W 5% TO220
- Datasheet Download
- PF2203-0R033J1.pdf
Availability of PF2203-0R033J1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.48350
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PF2203-0R033J1, we specialize in Riedon all series electronic components. PF2203-0R033J1 can be shipped within 24 hours after order. If you have any demands for PF2203-0R033J1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PF2203-0R033J1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PF2203-0R033J1
| Internal Part Number | EIS-PF2203-0R033J1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Power Resistor Heatsinks LED Lighting and Resistors Non-Inductive Thin Film Power Resistors | |
| Featured Product | TO-Style Power Resistors Lower cost TO-220 style Thin Film Power Resistors High-Power TO Style Resistors | |
| Standard Package | 50 | |
| Category | Resistors | |
| Family | Through Hole Resistors | |
| Series | PF2200 | |
| Packaging | Tube | |
| Resistance (Ohms) | 0.033 | |
| Tolerance | ±5% | |
| Power (Watts) | 35W | |
| Composition | Thin Film | |
| Features | - | |
| Temperature Coefficient | ±250ppm/°C | |
| Operating Temperature | -55°C ~ 155°C | |
| Package / Case | TO-220-2 | |
| Supplier Device Package | TO-220 | |
| Size / Dimension | 0.417" L x 0.177" W (10.60mm x 4.50mm) | |
| Height | 0.591" (15.00mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PF2203-0R033J1 | |
| Related Links | PF2203-, PF2203-0R033J1 Datasheet, Riedon Distributor | |
PF2203-0R033J1 Details Description
