Riedon PFS35-240RF1
- Mfg. Part Number
- PFS35-240RF1
- Manufacturer
- Riedon
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 240 OHM 1% 35W TO263
- Datasheet Download
- PFS35-240RF1.pdf
Availability of PFS35-240RF1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.77190
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PFS35-240RF1, we specialize in Riedon all series electronic components. PFS35-240RF1 can be shipped within 24 hours after order. If you have any demands for PFS35-240RF1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PFS35-240RF1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PFS35-240RF1
| Internal Part Number | EIS-PFS35-240RF1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Power Resistor Heatsinks Non-Inductive Thin Film Power Resistors | |
| Featured Product | High-Power TO Style Resistors | |
| Standard Package | 500 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | PFS35 | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 240 | |
| Tolerance | ±1% | |
| Power (Watts) | 35W | |
| Composition | Thin Film | |
| Features | - | |
| Temperature Coefficient | ±50ppm/°C | |
| Operating Temperature | -55°C ~ 155°C | |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | |
| Supplier Device Package | TO-263 (D-Pak) | |
| Size / Dimension | 0.406" L x 0.398" W (10.30mm x 10.10mm) | |
| Height | 0.185" (4.70mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PFS35-240RF1 | |
| Related Links | PFS35-, PFS35-240RF1 Datasheet, Riedon Distributor | |
PFS35-240RF1 Details Description
