Vishay Thin Film PHP00805H76R8BBT1
.jpg)
- Mfg. Part Number
- PHP00805H76R8BBT1
- Manufacturer
- Vishay Thin Film
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 76.8 OHM 0.1% 5/8W 0805
- Datasheet Download
- PHP00805H76R8BBT1.pdf
Availability of PHP00805H76R8BBT1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.62510
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PHP00805H76R8BBT1, we specialize in Vishay Thin Film all series electronic components. PHP00805H76R8BBT1 can be shipped within 24 hours after order. If you have any demands for PHP00805H76R8BBT1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PHP00805H76R8BBT1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PHP00805H76R8BBT1
| Internal Part Number | EIS-PHP00805H76R8BBT1 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Thin Film PHP Chip Resistors | |
| Standard Package | 1,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | PHP | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 76.8 | |
| Tolerance | ±0.1% | |
| Power (Watts) | 0.63W, 5/8W | |
| Composition | Thin Film | |
| Features | Flame Proof, Moisture Resistant, Safety | |
| Temperature Coefficient | ±50ppm/°C | |
| Operating Temperature | -55°C ~ 155°C | |
| Package / Case | 0805 (2012 Metric) | |
| Supplier Device Package | 0805 | |
| Size / Dimension | 0.080" L x 0.050" W (2.03mm x 1.27mm) | |
| Height | 0.033" (0.84mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PHP00805H76R8BBT1 | |
| Related Links | PHP00805, PHP00805H76R8BBT1 Datasheet, Vishay Thin Film Distributor | |
