Microchip Technology PIC16LC926T-I/L
- Mfg. Part Number
- PIC16LC926T-I/L
- Manufacturer
- Microchip Technology
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8BIT 14KB OTP 68PLCC
- Datasheet Download
- PIC16LC926T-I/L.pdf
Availability of PIC16LC926T-I/L
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PIC16LC926T-I/L, we specialize in Microchip Technology all series electronic components. PIC16LC926T-I/L can be shipped within 24 hours after order. If you have any demands for PIC16LC926T-I/L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PIC16LC926T-I/L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PIC16LC926T-I/L
| Internal Part Number | EIS-PIC16LC926T-I/L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Standard Package | 300 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | PIC® 16C | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | PIC | |
| Core Size | 8-Bit | |
| Speed | 20MHz | |
| Connectivity | I²C, SPI | |
| Peripherals | Brown-out Detect/Reset, LCD, POR, PWM, WDT | |
| Number of I/O | 25 | |
| Program Memory Size | 14KB (8K x 14) | |
| Program Memory Type | OTP | |
| EEPROM Size | - | |
| RAM Size | 336 x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.5 V ~ 5.5 V | |
| Data Converters | A/D 5x10b | |
| Oscillator Type | External | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 68-LCC (J-Lead) | |
| Supplier Device Package | 68-PLCC (24.23x24.23) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PIC16LC926T-I/L | |
| Related Links | PIC16LC, PIC16LC926T-I/L Datasheet, Microchip Technology Distributor | |
PIC16LC926T-I/L Details Description
