CUI Inc. PJ-005B
- Mfg. Part Number
- PJ-005B
- Manufacturer
- CUI Inc.
- Product Category
- Barrel - Power Connectors
- Brief Description
- CONNECTOR 2.5MM JACK PANEL MNT
- Datasheet Download
- PJ-005B.pdf
Availability of PJ-005B
Available Quantity
49377 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.03350
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PJ-005B, we specialize in CUI Inc. all series electronic components. PJ-005B can be shipped within 24 hours after order. If you have any demands for PJ-005B, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PJ-005B Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PJ-005B
| Internal Part Number | EIS-PJ-005B | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | PJ-005B Cert of Compliance | |
| 3D Model | PJ-005B | |
| Standard Package | 500 | |
| Category | Connectors, Interconnects | |
| Family | Barrel - Power Connectors | |
| Series | - | |
| Connector Type | Jack | |
| Gender | Male | |
| Plug/Mating Plug Diameter | 2.5mm ID, 5.5mm OD | |
| Number of Positions/Contacts | 2 Conductors, 3 Contacts | |
| Internal Switch(s) | Single Switch, Normally Closed | |
| Mounting Type | Panel Mount, Bulkhead - Front Side Nut | |
| Termination | Solder Eyelet(s) | |
| Shielding | Unshielded | |
| Features | Mounting Hardware, Thread Lock | |
| Color | Black | |
| Voltage - Rated | 16VDC | |
| Current Rating | 2A | |
| Contact Material | Copper | |
| Contact Material - Plating | Nickel | |
| Housing Color | Black | |
| Housing Material | Thermoplastic | |
| Operating Temperature | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PJ-005B | |
| Related Links | PJ-, PJ-005B Datasheet, CUI Inc. Distributor | |
PJ-005B Details Description
