NXP Semiconductors/Freescale Semiconductor, Inc. PMEG2010BELD,315
- Mfg. Part Number
- PMEG2010BELD,315
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE SCHOTTKY 20V 1A SOD882
- Datasheet Download
- PMEG2010BELD,315.pdf
Availability of PMEG2010BELD,315
Available Quantity
15020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.08241
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PMEG2010BELD,315, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. PMEG2010BELD,315 can be shipped within 24 hours after order. If you have any demands for PMEG2010BELD,315, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PMEG2010BELD,315 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PMEG2010BELD,315
| Internal Part Number | EIS-PMEG2010BELD,315 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Datasheet Update 24/Jun/2015 | |
| PCN Packaging | Lighter Reels 02/Jan/2014 Leadframe Material Update 20/Mar/2014 | |
| Standard Package | 10,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Diode Type | Schottky | |
| Voltage - DC Reverse (Vr) (Max) | 20V | |
| Current - Average Rectified (Io) | 1A | |
| Voltage - Forward (Vf) (Max) @ If | 490mV @ 1A | |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | 1.6ns | |
| Current - Reverse Leakage @ Vr | 200µA @ 20V | |
| Capacitance @ Vr, F | 40pF @ 1V, 1MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | SOD-882 | |
| Supplier Device Package | SOD-882 | |
| Operating Temperature - Junction | 150°C (Max) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PMEG2010BELD,315 | |
| Related Links | PMEG2010, PMEG2010BELD,315 Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
