Panduit PNF10-8LF-D
- Mfg. Part Number
- PNF10-8LF-D
- Manufacturer
- Panduit
- Product Category
- Terminals - Spade Connectors
- Brief Description
- TERM LOCK/FORK NYL 12-10AWG #8
- Datasheet Download
- PNF10-8LF-D.pdf
Availability of PNF10-8LF-D
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.51180
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PNF10-8LF-D, we specialize in Panduit all series electronic components. PNF10-8LF-D can be shipped within 24 hours after order. If you have any demands for PNF10-8LF-D, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PNF10-8LF-D Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PNF10-8LF-D
| Internal Part Number | EIS-PNF10-8LF-D | |
| Lead Free Status / RoHS Status | ||
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 500 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - Spade Connectors | |
| Series | Pan-Term® | |
| Packaging | Bulk | |
| Terminal Type | Spring, Snap | |
| Stud/Tab Size | 8 Stud | |
| Width - Outer Edges | 0.300" (7.62mm) | |
| Length - Overall | 1.050" (26.67mm) | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Wire Gauge | 10-12 AWG | |
| Insulation | Insulated | |
| Features | Serrated Termination | |
| Color | Yellow | |
| Contact Finish | Tin | |
| Contact Material | Copper | |
| Insulation Diameter | 0.225" (5.72mm) | |
| Material - Insulation | Polyamide (PA), Nylon | |
| Length - Ring Center to Termination | - | |
| Length - Termination | - | |
| Tongue Inside Opening | 0.160" (4.06mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PNF10-8LF-D | |
| Related Links | PNF10, PNF10-8LF-D Datasheet, Panduit Distributor | |
