CEL (California Eastern Laboratories) PS9531-AX
- Mfg. Part Number
- PS9531-AX
- Manufacturer
- CEL (California Eastern Laboratories)
- Product Category
- Isolators - Gate Drivers
- Brief Description
- OPTOISO 5KV GATE DRIVER 8DIP
- Datasheet Download
- PS9531-AX.pdf
Availability of PS9531-AX
Available Quantity
5134 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.37640
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PS9531-AX, we specialize in CEL (California Eastern Laboratories) all series electronic components. PS9531-AX can be shipped within 24 hours after order. If you have any demands for PS9531-AX, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PS9531-AX Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PS9531-AX
| Internal Part Number | EIS-PS9531-AX | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | CEL - PS9531 Isolated Gate-Drive Optocoupler | |
| Standard Package | 50 | |
| Category | Isolators | |
| Family | Isolators - Gate Drivers | |
| Series | - | |
| Packaging | Tube | |
| Technology | Optical Coupling | |
| Number of Channels | 1 | |
| Voltage - Isolation | 5000Vrms | |
| Common Mode Transient Immunity (Min) | 50kV/µs | |
| Propagation Delay tpLH / tpHL (Max) | 175ns, 175ns | |
| Pulse Width Distortion (Max) | 75ns | |
| Rise / Fall Time (Typ) | 40ns, 40ns | |
| Current - Output High, Low | 2A, 2A | |
| Current - Peak Output | 2.5A | |
| Voltage - Forward (Vf) (Typ) | 1.56V | |
| Current - DC Forward (If) (Max) | 25mA | |
| Voltage - Supply | 15 V ~ 30 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Through Hole | |
| Package / Case | 8-DIP (0.300", 7.62mm) | |
| Supplier Device Package | 8-DIP | |
| Approvals | CSA, SEMKO, UL | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PS9531-AX | |
| Related Links | PS95, PS9531-AX Datasheet, CEL (California Eastern Laboratories) Distributor | |
PS9531-AX Details Description
