Texas Instruments PTH08T221WAST
- Mfg. Part Number
- PTH08T221WAST
- Manufacturer
- Texas Instruments
- Product Category
- DC DC Converters
- Brief Description
- PTH08T221WAST
- Datasheet Download
- PTH08T221WAST.pdf
Availability of PTH08T221WAST
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 16.54125
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PTH08T221WAST, we specialize in Texas Instruments all series electronic components. PTH08T221WAST can be shipped within 24 hours after order. If you have any demands for PTH08T221WAST, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PTH08T221WAST Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PTH08T221WAST
| Internal Part Number | EIS-PTH08T221WAST | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Manufacturer Product Page | PTH08T221WAST Specifications | |
| Standard Package | 250 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | PTH04T221W | |
| Packaging | Tape & Reel (TR) | |
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 14V | |
| Voltage - Output 1 | 0.69 ~ 5.5 V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 16A | |
| Power (Watts) - Manufacture Series | - | |
| Voltage - Isolation | - | |
| Features | Remote On/Off, OCP, OTP, UVLO | |
| Mounting Type | Surface Mount | |
| Package / Case | 11-SMD Module | |
| Size / Dimension | 0.87" L x 0.75" W x 0.36" H (22.1mm x 19.1mm x 9.1mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 95% | |
| Power (Watts) - Max | 88W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PTH08T221WAST | |
| Related Links | PTH08T, PTH08T221WAST Datasheet, Texas Instruments Distributor | |
