C&K Components PTS840 JMP SMTR LFS
- Mfg. Part Number
- PTS840 JMP SMTR LFS
- Manufacturer
- C&K Components
- Product Category
- Tactile Switches
- Brief Description
- SWITCH TACTILE SPST-NO 0.05A 12V
- Datasheet Download
- PTS840 JMP SMTR LFS.pdf
Availability of PTS840 JMP SMTR LFS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of PTS840 JMP SMTR LFS, we specialize in C&K Components all series electronic components. PTS840 JMP SMTR LFS can be shipped within 24 hours after order. If you have any demands for PTS840 JMP SMTR LFS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- PTS840 JMP SMTR LFS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
PTS840 JMP SMTR LFS
| Internal Part Number | EIS-PTS840 JMP SMTR LFS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,500 | |
| Category | Switches | |
| Family | Tactile Switches | |
| Series | PTS840 | |
| Packaging | Tape & Reel (TR) | |
| Circuit | SPST-NO | |
| Switch Function | Off-Mom | |
| Contact Rating @ Voltage | 0.05A @ 12VDC | |
| Actuator Type | Rectangular Button | |
| Mounting Type | Surface Mount, Right Angle | |
| Actuator Height off PCB, from Pins | - | |
| Actuator Orientation | Side Actuated | |
| Termination Style | J Lead | |
| Outline | 3.55mm x 3.50mm | |
| Illumination | Non-Illuminated | |
| Illumination Voltage (Nominal) | - | |
| Illumination Type, Color | - | |
| Operating Force | 160gf | |
| Ingress Protection | - | |
| Features | Board Guide | |
| Actuator Material | - | |
| Switch Travel | 0.20mm | |
| Mechanical Life | 100,000 Cycles | |
| Operating Temperature | -40°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | PTS840 JMP SMTR LFS | |
| Related Links | PTS840 JM, PTS840 JMP SMTR LFS Datasheet, C&K Components Distributor | |
PTS840 JMP SMTR LFS Details Description
