Renesas Electronics America R5F100BDANA#W0
- Mfg. Part Number
- R5F100BDANA#W0
- Manufacturer
- Renesas Electronics America
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 16BIT 48KB FLASH 32HWQFN
- Datasheet Download
- R5F100BDANA#W0.pdf
Availability of R5F100BDANA#W0
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.70240
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of R5F100BDANA#W0, we specialize in Renesas Electronics America all series electronic components. R5F100BDANA#W0 can be shipped within 24 hours after order. If you have any demands for R5F100BDANA#W0, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- R5F100BDANA#W0 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
R5F100BDANA#W0
| Internal Part Number | EIS-R5F100BDANA#W0 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | RL78/G13 | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | RL78 | |
| Core Size | 16-Bit | |
| Speed | 32MHz | |
| Connectivity | CSI, I²C, LIN, UART/USART | |
| Peripherals | DMA, LVD, POR, PWM, WDT | |
| Number of I/O | 22 | |
| Program Memory Size | 48KB (48K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 3K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.6 V ~ 5.5 V | |
| Data Converters | A/D 8x8/10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 32-WFQFN Exposed Pad | |
| Supplier Device Package | 32-HWQFN (5x5) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | R5F100BDANA#W0 | |
| Related Links | R5F100B, R5F100BDANA#W0 Datasheet, Renesas Electronics America Distributor | |
R5F100BDANA#W0 Details Description
