Renesas Electronics America R5F21335TNFP#X6
- Mfg. Part Number
- R5F21335TNFP#X6
- Manufacturer
- Renesas Electronics America
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 16BIT 24KB FLASH 32LQFP
- Datasheet Download
- R5F21335TNFP#X6.pdf
Availability of R5F21335TNFP#X6
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of R5F21335TNFP#X6, we specialize in Renesas Electronics America all series electronic components. R5F21335TNFP#X6 can be shipped within 24 hours after order. If you have any demands for R5F21335TNFP#X6, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- R5F21335TNFP#X6 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
R5F21335TNFP#X6
| Internal Part Number | EIS-R5F21335TNFP#X6 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Featured Product | Flasher Series of Production Tools | |
| PCN Obsolescence/ EOL | Multiple Devices 15/Jun/2014 | |
| PCN Design/Specification | R8C/M16C Material Change 15/May/2013 | |
| Standard Package | 1,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | R8C/3x/33T | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | R8C | |
| Core Size | 16-Bit | |
| Speed | 20MHz | |
| Connectivity | I²C, LIN, SIO, SSU, UART/USART | |
| Peripherals | POR, PWM, Voltage Detect, WDT | |
| Number of I/O | 27 | |
| Program Memory Size | 24KB (24K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 2K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.8 V ~ 5.5 V | |
| Data Converters | A/D 12x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -20°C ~ 85°C | |
| Package / Case | 32-LQFP | |
| Supplier Device Package | 32-LQFP (7x7) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | R5F21335TNFP#X6 | |
| Related Links | R5F2133, R5F21335TNFP#X6 Datasheet, Renesas Electronics America Distributor | |
