Sullins Connector Solutions RBB10DHBS
- Mfg. Part Number
- RBB10DHBS
- Manufacturer
- Sullins Connector Solutions
- Product Category
- Card Edge Connectors - Edgeboard Connectors
- Brief Description
- CONN EDGECARD 20POS R/A .050 DIP
- Datasheet Download
- RBB10DHBS.pdf
Availability of RBB10DHBS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 11.47200
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RBB10DHBS, we specialize in Sullins Connector Solutions all series electronic components. RBB10DHBS can be shipped within 24 hours after order. If you have any demands for RBB10DHBS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RBB10DHBS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RBB10DHBS
| Internal Part Number | EIS-RBB10DHBS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Card Edge Connectors - Edgeboard Connectors | |
| Series | - | |
| Packaging | Tube | |
| Card Type | Non Specified - Dual Edge | |
| Gender | Female | |
| Number of Positions/Bay/Row | 10 | |
| Number of Positions | 20 | |
| Card Thickness | 0.062" (1.57mm) | |
| Number of Rows | 2 | |
| Pitch | 0.050" (1.27mm) | |
| Features | - | |
| Mounting Type | Through Hole, Right Angle | |
| Termination | Solder, Staggered | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 10µin (0.25µm) | |
| Contact Type | Hairpin Bellows | |
| Color | Black | |
| Flange Feature | Side Mount Opening, Unthreaded, 0.125" (3.18mm) Dia | |
| Operating Temperature | -65°C ~ 125°C | |
| Material - Insulation | Polyphenylene Sulfide (PPS) | |
| Read Out | Dual | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RBB10DHBS | |
| Related Links | RBB1, RBB10DHBS Datasheet, Sullins Connector Solutions Distributor | |
RBB10DHBS Details Description
