Yageo RC0805FR-074M02L
- Mfg. Part Number
- RC0805FR-074M02L
- Manufacturer
- Yageo
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 4.02M OHM 1% 1/8W 0805
- Datasheet Download
- RC0805FR-074M02L.pdf
Availability of RC0805FR-074M02L
Available Quantity
15020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.00198
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RC0805FR-074M02L, we specialize in Yageo all series electronic components. RC0805FR-074M02L can be shipped within 24 hours after order. If you have any demands for RC0805FR-074M02L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RC0805FR-074M02L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RC0805FR-074M02L
| Internal Part Number | EIS-RC0805FR-074M02L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Chip Resistor | |
| PCN Other | RC/AC 0603/0805/1206 22/Jan/2013 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 5,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | RC | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 4.02M | |
| Tolerance | ±1% | |
| Power (Watts) | 0.125W, 1/8W | |
| Composition | Thick Film | |
| Features | Moisture Resistant | |
| Temperature Coefficient | ±100ppm/°C | |
| Operating Temperature | -55°C ~ 155°C | |
| Package / Case | 0805 (2012 Metric) | |
| Supplier Device Package | 0805 | |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | |
| Height | 0.024" (0.60mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RC0805FR-074M02L | |
| Related Links | RC0805FR, RC0805FR-074M02L Datasheet, Yageo Distributor | |
