Ohmite RC0R5DB560RJE
- Mfg. Part Number
- RC0R5DB560RJE
- Manufacturer
- Ohmite
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 560 OHM 5% 1/2W J LEAD
- Datasheet Download
- RC0R5DB560RJE.pdf
Availability of RC0R5DB560RJE
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.97060
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RC0R5DB560RJE, we specialize in Ohmite all series electronic components. RC0R5DB560RJE can be shipped within 24 hours after order. If you have any demands for RC0R5DB560RJE, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RC0R5DB560RJE Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RC0R5DB560RJE
| Internal Part Number | EIS-RC0R5DB560RJE | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 100 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | RC | |
| Packaging | Bulk | |
| Resistance (Ohms) | 560 | |
| Tolerance | ±5% | |
| Power (Watts) | 0.5W, 1/2W | |
| Composition | Carbon Composition | |
| Features | Pulse Withstanding | |
| Temperature Coefficient | ±400ppm/°C | |
| Operating Temperature | -55°C ~ 150°C | |
| Package / Case | 6327 J-Lead | |
| Supplier Device Package | SMD J-Lead, Recessed | |
| Size / Dimension | 0.625" L x 0.273" W (15.88mm x 6.93mm) | |
| Height | 0.231" (5.87mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RC0R5DB560RJE | |
| Related Links | RC0R5D, RC0R5DB560RJE Datasheet, Ohmite Distributor | |
RC0R5DB560RJE Details Description
