Recom Power REC5-4805DRWZ/H2/A/M/SMD/CTRL

REC5-4805DRWZ/H2/A/M/SMD/CTRL picture photo
Mfg. Part Number
REC5-4805DRWZ/H2/A/M/SMD/CTRL
Manufacturer
Product Category
DC DC Converters
Brief Description
CONV DC/DC 5W 18-72VIN +/-05VOUT
Datasheet Download
REC5-4805DRWZ/H2/A/M/SMD/CTRL.pdf
Availability of REC5-4805DRWZ/H2/A/M/SMD/CTRL

Available Quantity

5020 Pieces

Can ship today


Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks

Marketing Price
$ 28.06400
Our Price
Quote by Email

QUANTITY



EIS Components is the stocking Distributor of REC5-4805DRWZ/H2/A/M/SMD/CTRL, we specialize in Recom Power all series electronic components. REC5-4805DRWZ/H2/A/M/SMD/CTRL can be shipped within 24 hours after order. If you have any demands for REC5-4805DRWZ/H2/A/M/SMD/CTRL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
REC5-4805DRWZ/H2/A/M/SMD/CTRL Order Process
Add Parts to RFQ form
Submit RFQ
We reply within 24 hours
You confirm order
Payment
Ship out your order
Specifications of REC5-4805DRWZ/H2/A/M/SMD/CTRL
Internal Part NumberEIS-REC5-4805DRWZ/H2/A/M/SMD/CTRL
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
Standard Package15
Category Power Supplies - Board Mount
FamilyDC DC Converters
SeriesECONOLINE REC5
PackagingTube
TypeIsolated Module
Number of Outputs2
Voltage - Input (Min)18V
Voltage - Input (Max)72V
Voltage - Output 15V
Voltage - Output 2-5V
Voltage - Output 3-
Current - Output (Max)500mA, 500mA
Power (Watts) - Manufacture Series5W
Voltage - Isolation2kV (2000V)
FeaturesRemote On/Off, SCP
Mounting TypeSurface Mount
Package / Case24-SMD Module (18 Leads)
Size / Dimension1.26" L x 0.78" W x 0.44" H (32.0mm x 19.9mm x 11.2mm)
Operating Temperature-40°C ~ 75°C
Efficiency82%
Power (Watts) - Max5W
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)REC5-4805DRWZ/H2/A/M/SMD/CTRL
Related LinksREC5-4805DRWZ/, REC5-4805DRWZ/H2/A/M/SMD/CTRL Datasheet, Recom Power Distributor
REC5-4805DRWZ/H2/A/M/SMD/CTRL Details Description
