Texas Instruments REF1004I-1.2/2K5
- Mfg. Part Number
- REF1004I-1.2/2K5
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Voltage Reference
- Brief Description
- IC VREF SHUNT 1.235V 8SOIC
- Datasheet Download
- REF1004I-1.2/2K5.pdf
Availability of REF1004I-1.2/2K5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.28510
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of REF1004I-1.2/2K5, we specialize in Texas Instruments all series electronic components. REF1004I-1.2/2K5 can be shipped within 24 hours after order. If you have any demands for REF1004I-1.2/2K5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- REF1004I-1.2/2K5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
REF1004I-1.2/2K5
| Internal Part Number | EIS-REF1004I-1.2/2K5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Reference | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Reference Type | Shunt | |
| Output Type | Fixed | |
| Voltage - Output (Min/Fixed) | 1.235V | |
| Voltage - Output (Max) | - | |
| Current - Output | 20mA | |
| Tolerance | ±0.3% | |
| Temperature Coefficient | 20ppm/°C Typical | |
| Noise - 0.1Hz to 10Hz | - | |
| Noise - 10Hz to 10kHz | 60µVrms | |
| Voltage - Input | - | |
| Current - Supply | - | |
| Current - Cathode | 10µA | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | REF1004I-1.2/2K5 | |
| Related Links | REF1004I, REF1004I-1.2/2K5 Datasheet, Texas Instruments Distributor | |
REF1004I-1.2/2K5 Details Description
