Bourns Inc. RLB0914-390KL

RLB0914-390KL picture photo
Mfg. Part Number
RLB0914-390KL
Manufacturer
Product Category
Fixed Inductors
Brief Description
FIXED IND 39UH 1.6A 130 MOHM TH
Datasheet Download
RLB0914-390KL.pdf
Availability of RLB0914-390KL

Available Quantity

5020 Pieces

Can ship today


Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks

Marketing Price
$ 0.16800
Our Price
Quote by Email

QUANTITY



EIS Components is the stocking Distributor of RLB0914-390KL, we specialize in Bourns Inc. all series electronic components. RLB0914-390KL can be shipped within 24 hours after order. If you have any demands for RLB0914-390KL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
RLB0914-390KL Order Process
Add Parts to RFQ form
Submit RFQ
We reply within 24 hours
You confirm order
Payment
Ship out your order
Specifications of RLB0914-390KL
Internal Part NumberEIS-RLB0914-390KL
Lead Free Status / RoHS StatusLead free / RoHS Compliant
Moisture Sensitivity Level (MSL)1 (Unlimited)
Production Status (Lifecycle)In Production
ConditionNew & Unused, Original Sealed
Product Training ModulesMagnetic Product Overview
PCN Assembly/OriginMagnetic products Oct/2013
EDA / CAD ModelsDownload from Accelerated Designs
Standard Package200
Category Inductors, Coils, Chokes
FamilyFixed Inductors
SeriesRLB
PackagingBulk
TypeWirewound
Material - CoreFerrite
Inductance39µH
Tolerance±10%
Current Rating1.6A
Current - Saturation-
ShieldingUnshielded
DC Resistance (DCR)130 mOhm Max
Q @ Freq30 @ 2.52MHz
Frequency - Self Resonant7MHz
Operating Temperature-40°C ~ 105°C
Frequency - Test2.52MHz
Mounting TypeThrough Hole
Package / CaseRadial
Size / Dimension0.343" Dia (8.70mm)
Height - Seated (Max)0.512" (13.00mm)
Supplier Device Package-
Weight0.001 KG
ApplicationEmail for details
Alternative Part (Replacement)RLB0914-390KL
Related LinksRLB091, RLB0914-390KL Datasheet, Bourns Inc. Distributor
RLB0914-390KL Details Description
