TE Connectivity Potter & Brumfield Relays RM502024
- Mfg. Part Number
- RM502024
- Manufacturer
- TE Connectivity Potter & Brumfield Relays
- Product Category
- Power Relays, Over 2 Amps
- Brief Description
- RELAY GEN PURPOSE DPST 16A 24V
- Datasheet Download
- RM502024.pdf
Availability of RM502024
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 9.48000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RM502024, we specialize in TE Connectivity Potter & Brumfield Relays all series electronic components. RM502024 can be shipped within 24 hours after order. If you have any demands for RM502024, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RM502024 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RM502024
| Internal Part Number | EIS-RM502024 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Relays | |
| Family | Power Relays, Over 2 Amps | |
| Series | RM, SCHRACK | |
| Packaging | Bulk | |
| Relay Type | General Purpose | |
| Coil Type | Non Latching | |
| Coil Current | 70.8mA | |
| Coil Voltage | 24VDC | |
| Contact Form | DPST (2 Form A) | |
| Contact Rating (Current) | 16A | |
| Switching Voltage | 440VAC - Max | |
| Turn On Voltage (Max) | 18 VDC | |
| Turn Off Voltage (Min) | 2.4 VDC | |
| Operate Time | 20ms | |
| Release Time | 5ms | |
| Features | - | |
| Mounting Type | Socketable | |
| Termination Style | Plug In, Quick Connect - 0.187" (4.7mm) | |
| Contact Material | Silver Cadmium Oxide (AgCdO) | |
| Coil Power | 1.7 W | |
| Coil Resistance | 345 Ohms | |
| Operating Temperature | -45°C ~ 50°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RM502024 | |
| Related Links | RM50, RM502024 Datasheet, TE Connectivity Potter & Brumfield Relays Distributor | |
RM502024 Details Description
