Schaffner EMC Inc. RN122-0.8-02
- Mfg. Part Number
- RN122-0.8-02
- Manufacturer
- Schaffner EMC Inc.
- Product Category
- Common Mode Chokes
- Brief Description
- CHOKE COMPENSATED 39MH .8A HORZ
- Datasheet Download
- RN122-0.8-02.pdf
Availability of RN122-0.8-02
Available Quantity
5219 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.74230
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RN122-0.8-02, we specialize in Schaffner EMC Inc. all series electronic components. RN122-0.8-02 can be shipped within 24 hours after order. If you have any demands for RN122-0.8-02, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RN122-0.8-02 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RN122-0.8-02
| Internal Part Number | EIS-RN122-0.8-02 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | RN Choke Series | |
| Featured Product | RFI Suppression Chokes RN Series Chokes | |
| Standard Package | 20 | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Series | RN | |
| Packaging | Tray | |
| Filter Type | Power Line | |
| Number of Lines | 2 | |
| Inductance | 39mH | |
| Current | 800mA | |
| DC Resistance (DCR) | 1 Ohm | |
| Impedance | - | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Through Hole | |
| Size / Dimension | 1.102" L x 1.063" W (28.00mm x 27.00mm) | |
| Height (Max) | 0.661" (16.80mm) | |
| Package / Case | Horizontal, 4 PC Pin | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RN122-0.8-02 | |
| Related Links | RN122-, RN122-0.8-02 Datasheet, Schaffner EMC Inc. Distributor | |
