Vishay/Dale RN55C2803BBSL
- Mfg. Part Number
- RN55C2803BBSL
- Manufacturer
- Vishay/Dale
- Product Category
- Through Hole Resistors
- Brief Description
- RES 280K OHM 1/8W .1% AXIAL
- Datasheet Download
- RN55C2803BBSL.pdf
Availability of RN55C2803BBSL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.38600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of RN55C2803BBSL, we specialize in Vishay/Dale all series electronic components. RN55C2803BBSL can be shipped within 24 hours after order. If you have any demands for RN55C2803BBSL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- RN55C2803BBSL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
RN55C2803BBSL
| Internal Part Number | EIS-RN55C2803BBSL | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 100 | |
| Category | Resistors | |
| Family | Through Hole Resistors | |
| Series | Military, MIL-R-10509/7, RN55 | |
| Packaging | Bulk | |
| Resistance (Ohms) | 280k | |
| Tolerance | ±0.1% | |
| Power (Watts) | 0.125W, 1/8W | |
| Composition | Metal Film | |
| Features | Flame Retardant Coating, Military, Moisture Resistant, Safety | |
| Temperature Coefficient | ±50ppm/°C | |
| Package / Case | Axial | |
| Supplier Device Package | Axial | |
| Size / Dimension | 0.090" Dia x 0.240" L (2.29mm x 6.10mm) | |
| Height | - | |
| Number of Terminations | 2 | |
| Failure Rate | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | RN55C2803BBSL | |
| Related Links | RN55C2, RN55C2803BBSL Datasheet, Vishay/Dale Distributor | |
