API Delevan S0603-101NH3E
- Mfg. Part Number
- S0603-101NH3E
- Manufacturer
- API Delevan
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 100NH 400MA 610 MOHM
- Datasheet Download
- S0603-101NH3E.pdf
Availability of S0603-101NH3E
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 17.66100
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of S0603-101NH3E, we specialize in API Delevan all series electronic components. S0603-101NH3E can be shipped within 24 hours after order. If you have any demands for S0603-101NH3E, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- S0603-101NH3E Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
S0603-101NH3E
| Internal Part Number | EIS-S0603-101NH3E | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | S0603 | |
| Packaging | Bulk | |
| Type | Wirewound | |
| Material - Core | Alumina | |
| Inductance | 100nH | |
| Tolerance | ±3% | |
| Current Rating | 400mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 610 mOhm Max | |
| Q @ Freq | 31 @ 150MHz | |
| Frequency - Self Resonant | 1.4GHz | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 150MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 0603 (1608 Metric) | |
| Size / Dimension | 0.062" L x 0.035" W (1.58mm x 0.89mm) | |
| Height - Seated (Max) | 0.040" (1.02mm) | |
| Supplier Device Package | 0603 (1608 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | S0603-101NH3E | |
| Related Links | S0603-, S0603-101NH3E Datasheet, API Delevan Distributor | |
S0603-101NH3E Details Description
