Riedon S1-0R2F1
- Mfg. Part Number
- S1-0R2F1
- Manufacturer
- Riedon
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 0.2 OHM 1% 1/2W 1913
- Datasheet Download
- S1-0R2F1.pdf
Availability of S1-0R2F1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.22400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of S1-0R2F1, we specialize in Riedon all series electronic components. S1-0R2F1 can be shipped within 24 hours after order. If you have any demands for S1-0R2F1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- S1-0R2F1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
S1-0R2F1
| Internal Part Number | EIS-S1-0R2F1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Wirewound Resistor Technology Pulse Rated Wirewound Resistors | |
| Standard Package | 300 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | S | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 0.2 | |
| Tolerance | ±1% | |
| Power (Watts) | 0.5W, 1/2W | |
| Composition | Wirewound | |
| Features | Flame Proof, Moisture Resistant, Pulse Withstanding, Safety | |
| Temperature Coefficient | - | |
| Operating Temperature | -55°C ~ 275°C | |
| Package / Case | 1913 J-Lead | |
| Supplier Device Package | - | |
| Size / Dimension | 0.189" L x 0.130" W (4.80mm x 3.30mm) | |
| Height | 0.126" (3.20mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | S1-0R2F1 | |
| Related Links | S1-0, S1-0R2F1 Datasheet, Riedon Distributor | |
S1-0R2F1 Details Description
