GeneSiC Semiconductor S70DR
- Mfg. Part Number
- S70DR
- Manufacturer
- GeneSiC Semiconductor
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE GEN PURP REV 200V 70A DO5
- Datasheet Download
- S70DR.pdf
Availability of S70DR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 7.28720
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of S70DR, we specialize in GeneSiC Semiconductor all series electronic components. S70DR can be shipped within 24 hours after order. If you have any demands for S70DR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- S70DR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
S70DR
| Internal Part Number | EIS-S70DR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 5 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | - | |
| Packaging | Bulk | |
| Diode Type | Standard, Reverse Polarity | |
| Voltage - DC Reverse (Vr) (Max) | 200V | |
| Current - Average Rectified (Io) | 70A | |
| Voltage - Forward (Vf) (Max) @ If | 1.1V @ 70A | |
| Speed | Standard Recovery >500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 10µA @ 100V | |
| Capacitance @ Vr, F | - | |
| Mounting Type | Chassis, Stud Mount | |
| Package / Case | DO-203AB, DO-5, Stud | |
| Supplier Device Package | DO-5 | |
| Operating Temperature - Junction | -65°C ~ 180°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | S70DR | |
| Related Links | S7, S70DR Datasheet, GeneSiC Semiconductor Distributor | |
S70DR Details Description
