Littelfuse S8055WTP
- Mfg. Part Number
- S8055WTP
- Manufacturer
- Littelfuse
- Product Category
- SCRs - Single
- Brief Description
- SCR NON-SENS 800V 55A TO-218X
- Datasheet Download
- S8055WTP.pdf
Availability of S8055WTP
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.88500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of S8055WTP, we specialize in Littelfuse all series electronic components. S8055WTP can be shipped within 24 hours after order. If you have any demands for S8055WTP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- S8055WTP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
S8055WTP
| Internal Part Number | EIS-S8055WTP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 250 | |
| Category | Discrete Semiconductor Products | |
| Family | SCRs - Single | |
| Series | - | |
| Packaging | Tube | |
| Voltage - Off State | 800V | |
| Voltage - Gate Trigger (Vgt) (Max) | 1.5V | |
| Current - Gate Trigger (Igt) (Max) | 40mA | |
| Voltage - On State (Vtm) (Max) | 1.8V | |
| Current - On State (It (AV)) (Max) | 35A | |
| Current - On State (It (RMS)) (Max) | 55A | |
| Current - Hold (Ih) (Max) | 60mA | |
| Current - Off State (Max) | 20µA | |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 550A, 650A | |
| SCR Type | Standard Recovery | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Through Hole | |
| Package / Case | TO-218X-3 | |
| Supplier Device Package | TO-218X | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | S8055WTP | |
| Related Links | S805, S8055WTP Datasheet, Littelfuse Distributor | |
S8055WTP Details Description
